40.5kV MSS Solid Dielectric Switchgear

The MSS H 40.5kV series solid fully enclosed switchgear is a novel type of fully insulated intelligent switchgear developed by our technical experts and European switching technical experts based on the concept of product life cycle and the internet of things. After nearly a decade of theoretical experimental research, field investigation, testing, and application, this equipment utilizes high thermal conductivity nano epoxy resin insulating material. The high-voltage conductive part of the switchgear is insulated and sealed, while the surface of the equipment's insulator is shielded and grounded with graphene. With its high-voltage conductive part being fully insulated, shielded, and grounded, this switchgear ensures true safety, high reliability under all working conditions; it is also intelligent, maintenance-free as well as detectable and predictable. Compliant with IEC and GB/DL standards, this comprehensive solution can meet various functional needs to create higher production value for customers.

Email:

info@gelpag.com

TEL

+49 (0)6206 95088 23

Message

For more details, please Contact!

Product application

Classification

MV Solid Insulated Switchgear

keyword

Product Description

Product features

The primary conductive part is fully solid insulated, not affected by the surrounding environment, and can withstand various harsh environments.

The insulation surface is shielded and grounded to prevent phase to phase short circuit fault.

The isolation fracture and grounding position can be seen to ensure safe operation and maintenance.

Using tubular copper bus, the electric field is evenly distributed, which effectively reduces the probability of tip discharge, and the local discharge of the whole cabinet is small.

The primary main circuit is really maintenance free.

No possibility of gas leakage.

Small volume and light weight, effectively saving construction area and civil engineering cost.

Technical specification

ltem		Unit	Data
Rated Voltage		kV	40.5
Rated Frequency		HZ	50/60
Rated Current		A	1250//2500
Rated 1min Power-frequency withstand voltage (Phase/ Distance)		kV	95/118
Rated lighting impulse withstand voltage (Phase/ Distance)		kV	185/1215
Rated Short-time Withstand Current Duration		KA	31.5/40
Peak Withstand Current		KA	80/100
Rated Short-time Withstand Current Duration		s	4
PD Level		pC	≤20
IP Class	Enclosure		IP4X
	Compartment		IP2X
	Main Circuit and all High-pressure Components		IP68

MSS dimension

ltem	Unit	Data
Height	mm	2300
Depth	mm	1800
Width	mm	800
Weight	kg	≤1500

Note: Different panels sizes can be configured according to customer project requirements.

Application scenarios

MSS is applied to large-scale enterprises such as power grid,power plant, petroleum and petrochemical, metallurgy, coal chemical industry and so on.It can also be used in municipal, port, wharf and other places.

It can also be used for special applications in a variety of geographical environments:
