General Information

Input Rating

400Vac±10%, 50/60Hz, L1+L2+L3+N+PE

Power Factor

≥0.98 @ Full Load

Efficiency

≥94% @ Full Load (Peak)

Grid Type

TN-S, TN-C, TN-C-S, TT

Output Interface

Configuration 01: 2 x CCS2 + Type2 Socket( or French socket available)

Configuration 02: CCS2 + CHAdeMO + Type2 Socket( or French socket available)

Configuration 03: CCS2 + CCS2

Output Power

DC 60kW max. + AC 22kW max.

Output Voltage

CCS2: 200-1000Vdc, Type2: 400Vac±10%, CHAdeMO: 200Vdc-500Vdc

Output Current

CCS2: 200A max./connector, Type2: 32A max, CHAdeMO: 125A max./connector

Charging Mode

Support simultaneous charging for all connectors.

User Interface

Display

7 inches touch screen

Support Language

English (Other languages available upon request)

Button and Switch

Emergency button

User Authentication

RFID card, App, Credit card (optional)

RFID Reader

ISO/IEC 14443 A/B, ISO/IEC 18092, IEC/ISO 15693

Communication

Network Interface

4G, Wi-Fi, Ethernet

Protocol (EVSE&Backend)

OCPP1.6J

Protocol (EVSE&EV)

DIN 70121, ISO 15118

Environmental

Operating Temperature

-30 to 50℃

Storage Temperature

-40 to 70℃

Humidity

5% to 95% no condensation

Altitude

≤2000m above sea level

Mechanical

IP Rating

IP55

IK Rating

IK10

Cooling

Forced Air

Charging Cable Length

5m

Dimensions (HxWxD)

1894x1050x710mm (including cable management system)

1650x700x457mm  (excluding cable management system, cable management system is optional)

Weight*

Approx. 200kg (excluding power modules)

Installation

Ground mounting

Certification and standards

Standards and compliance

IEC 61851-1, IEC 61851-21-2, IEC 61851-23, LVD 2014/35/EU, RED 2014/53/EU

Certification

CE-RED, CB, UKCA
